These
specifications apply to a standard model only.
Modifications may be made to suit.
Click here to print this page
|
Length |
19.5' |
| Beam |
7' |
| Bottom
Width (3/16 5086 al.
bottom.* Optional 3/8"
center section Delta shoe) |
6' |
| Bottom
Angle |
8
- 16 degrees |
| Reverse
chine |
Full
length |
| Ribbed
sides - 1/8" 5052 |
Full
length & 28" high |
| Deck |
Checkerplate |
| Walk
thru windshield |
3
mm safety glass |
| Side
trays |
Full
length |
| Dash
with step & Glove box |
|
| Infloor
welded al. fuel tank (Coast
Guard approved with
water separator/fuel filter) |
30
gallons |
| Foam
flotation |
|
| Flooring
is fiberglassed with marine vinyl decking |
|
| Marine
carpeting on interior sides |
Your
choice of colours. |
| Two
sleeper seats or two pedestal seats |
|
| Running
lights |
|
| Decals |
|
| Front
and rear railings & Deck cleats |
|
*Marine
grade aluminum that is 40% stronger.
Exterior
bottom has four lifting strikes on it for better handling and more lift.
Inside
bottom has two T bar on each side and 3/16"
formed main stringers.
|
