These
specifications apply to a standard model only.
Modifications may be made to suit.
Click here to print this page
|
Kodiak
350 Chev engine |
|
|
American
Turbine Jet |
SD
309 Pump |
|
Length |
19.5' |
|
Beam |
7' |
|
Bottom
Width (5/8" center
section of 5086* in a Delta V pad. Optional 3/4" Delta
Shoe center section) |
6' |
|
Bottom
Angle |
8
- 16 degrees |
|
Reverse
chine |
Full
length |
|
Ribbed
sides - 1/8" 5052 |
Full
length & 28" high |
|
Deck |
Checker plate |
|
Walk
thru windshield |
3
mm safety glass |
|
Side
trays |
Full
length |
|
Dash
with step & Glove box |
|
|
In floor
welded al. fuel tank (Coast Guard approved w/
water separator/fuel filter) |
30
- 45 gallons |
|
Foam
flotation |
|
|
Flooring
is fiber glassed with marine vinyl decking |
Color
= customer choice |
|
Marine
carpeting on interior sides |
Color
= customer choice |
|
Two
sleeper seats or two pedestal seats |
Color
= customer choice |
|
Running
lights |
|
|
Decals |
|
|
Front
and rear railings |
|
|
Deck
cleats |
|
|
Jet
Guard & Swim Grid |
|
*Marine grade aluminum that is 40% stronger
Exterior
bottom has four lifting strikes on it for better handling and more lift.
Inside
bottom has two T bar on each side and
1/4" formed main stringers.
|
