These
specifications apply to a standard model only.
Modifications may be made to suit.
click here to print
this page
|
Length |
17.5' |
|
Beam |
7' |
|
Bottom
Width (3/16 5086* one-piece al. bottom, optional
3/8" center section Delta shoe) |
6' |
|
Bottom
Angle |
12
degrees |
|
Reverse
chine |
Full
length |
|
Ribbed
sides - 1/8" 5052 |
Full
length & 28" high |
|
Deck |
Checker plate
|
|
Walk
thru windshield |
3
mm safety glass |
|
Side
trays |
Full
length |
|
Dash
with step & Glove box |
|
|
In floor
welded al. fuel tank (Coast
Guard
approved with water separator/fuel filter) |
30
gallons |
|
Foam
flotation |
|
|
Flooring
is fiber glassed with
marine vinyl decking |
|
|
Marine
carpeting on the interior sides |
Your
choice of colors. |
|
Two
sleeper seats or two pedestal seats |
|
|
Running
lights |
|
|
Decals |
|
|
Front
and rear railings and deck cleats |
|
*Marine
grade aluminum that is 40% stronger.
Exterior
bottom has four lifting strikes on it for better handling and more lift.
Inside bottom has two T bar on each side and a 3/16" formed main
stringers.
|
